This Pioneer CX-631 cassette mechanism assy CRT1640 Service Manual for KEH-P525, KEH-P5700, KEH-P5750 players describes operation of the cassette mechanism incorporated in KEH-P525, KEH-P5700, KEH-P5750 players. When performing repairs use this service manual CX-631 with the specific service manual for KEH-P525, KEH-P5700, KEH-P5750 models under repair.
CONTENTS
1. MECHANISM DESCRIPTION AND GREASING .........2
2. DISASSEMBLY ...................................................11
3. ADJUSTMENT .....................................................11
3.1 TAPE SPEED ADJUSTMENT..................................11
3.2 CHECK POINTS OF CASSETTE MECHANISM .........12
