This Service Manual describes basic functions, theory of electrical and mechanical operations, maintenance and repair procedures of the printer.
This manual consists of 4 chapters.
CHAPTER 1. DISASSEMBLY / ASSEMBLY
Describes the step-by-step procedures for disassembling and assembling the product.
CHAPTER 2. ADJUSTMENT
Provides Epson-approved methods for adjustment.
CHAPTER 3. MAINTENANCE
Provides preventive maintenance procedures and the lists of Epson-approved lubricants and adhesives required for servicing the product.
CHAPTER 4. APPENDIX Provides the following additional information for reference:
• Electrical circuit boards schematics
FORMAT: High resolution PDF document!
Zip archive: 1 218 kB
|
